HART475 manual operator

Performance:

HART ® The handset can be connected to any HART through a 4-20mA current loop ® For compatible equipment, there must be a load resistance of at least 250 Ω in this current loop. The HART handheld device adopts the high frequency digital signal Bell202 frequency shift keying (FSK) technology, which can be superimposed on the 4-20mA current signal for transmission. Handset and HART ® The communication of compatible equipment will not affect 4-20mA analog signal.

Technical indicators:

● HART ® Interface technical indicators

● HART ® Interface complies with HCF (HART ® Communication Foundation) protocol, two-way half duplex 1200bit/s mode

● HART ® The interface can receive a common mode voltage of&# 177; 40V

● Typical value of leakage current is less than 1uA@20 ℃

● HART ® Interface communication distance<1500m

● HART ® The communication interface has anti EMI measures

● HART ® Communication interface has automatic amplitude multiplication function

Physical dimensions:

● 165mm * 98mm * 32mm (without protective leather cover)

170mm * 86mm * 42mm (with protective leather cover)

Environmental requirements:

● Operating temperature range: 0 ℃ -+50 ℃

● Storage temperature range: - 20 ℃ -+55 ℃

Supported transmitter types:

HK-H3151, HK-H1151, HK-H990-CT1, HK-H610, YOKOKAWA EJA, Rosemount 1151, Rosemount 3051, HK-H990M (HART universal pressure rounding card), HK-H991M (universal pressure transmitter card), HK-H3351M (Huakong 3351 pressure rounding card), WT-2000 (Wiltai WT2000 pressure gauge), MV-2000 (Wiltai MV2000 pressure gauge), SIPART_ PS2 (SIMENS valve positioner), SITRANS_ FM_ MAG (SIMENS mass flowmeter), SITRANS_ TH300 (SIMENS thermometer).
