XYT110 Series Universal Temperature Transmitter

›

‹

  • XYT110 Series Universal Temperature Transmitter

›

XYT110 Series Universal Temperature Transmitter
The XYT110 series temperature transmitter adopts a high-resolution and high-precision temperature sensor probe as the measuring element, and the amplification circuit is located inside the stainless steel shell to convert the temperature into a standard signal output.
Download Attachment
Whatsapp : +86 17391983629‬
Email : Jayna@xinyiyb.com
CONTACT US

Product Description

XYT110 Series Universal Temperature Transmitter

Description

The XYT110 series temperature transmitter adopts a high-resolution and high-precision temperature sensor probe as the measuring element, and the amplification circuit is located inside the stainless steel shell to convert the temperature into a standard signal output.

This temperature transmitter is widely used for temperature measurement in industrial sites such as petroleum, chemical, metallurgical, power, and hydrological industries due to its excellent reliability, flexibility, and diversity.

Features

1.Temperature measurement resolution 0.1 ℃

2.The material in contact with the medium is stainless steel, which has good corrosion resistance

3.Suitable for temperature measurement of fluid media, long-term stable operation

4.Resistance to impact, vibration, and corrosion

Exterior structure

XYT110 Series Universal Temperature Transmitter

Electrical connection

XYT110 Series Universal Temperature Transmitter

Technical Parameter

Electrical Definition

Pin

Cable line

Power supply positive

（+V）

1

black

Output（+OUT）

2

red

Technical Parameter

Measuring range

-50℃~200℃

Power supply

10V~28V DC

Output signal

4mA～20mA DC（Two wire system）

Protection level

IP65

Accuracy

≤±0.5％FS

Ambient temperature

-20℃~80℃

Interface materia

stainless steel

Install thread

M20*1.5（Optional）
