Emerson ROSEMOUNT 3051 Pressure transmitter

Rosemount 3051 pressure transmitters have set industry standards for pressure measurement. This transmitter can be used to measure differential, absolute, or gage pressure. These pressure transmitters help improve production and operational efficiencies in various process industries. Equipped with Power Advisory Diagnostics and a Local Operator Interface (LOI), these pressure transmitters enable easy installation and help reduce commissioning times. They are designed to withstand tough environments in the process industries.

Download Attachment

Whatsapp : +86 17391983629‬

Email : Jayna@xinyiyb.com

Product Description

model	3051DP……
Measuring the dielectric	Gas,liquid,oil,or316LCompatible media
Range	1kPa~40MPa
Pressure type	Manometer pressure, absolute pressure, negative pressure
Accuracy	0.1%,0.2%,0.5%F.S
Power Voltage	14~45VDC
Output Signal	4~20mA/HART/ LCD
Ambient Temperature	-20~+80℃
Working Temperature	-40~+85℃
Related Moisture	0%~100%,LCD
External magnetic field	≤400A/m
Stability	±0.1%/ year
Temperature Influence	±0.1%/10℃
Install Location Influence	≤0.4kPa
Voltage Influence	≤±0.01%/V
Connector Material	Stainless Steel
Explosive-proof grade	ExdIICT6 ,ExiaIICT6
Sealing Ring Material	NBR/Viton/Customized
Material	Junction box: Low content Cu-Al alloy Probe: Stainless steel Cable: Polyurethane cable
Positive and negative transfe range	+500%,-600%
Isolation diaphragm material	316L, TAN,HC
procedure linkage	M20*1.5,G1/2,G1/4,1/2NPT,PT1/4

Rosemount 3051 transmitter Exploded View diagram

3051C Transmitter Online Configuration Quote

Select different 3051C model code combinations to quickly check transmitter configuration prices.

Message

Products Recommended



Pressure Transmitters for Industrial Pressure Measurement

Name: Emerson ROSEMOUNT 3051 Pressure transmitter
SKU: 0

Xinyi Instrument supplies pressure transmitters for process control, hydraulic systems, petrochemical plants, water treatment, HVAC, power generation and general industrial pressure monitoring. Our pressure transmitter range covers gauge pressure, absolute pressure, differential pressure, high temperature media and digital communication applications.

Choose from compact pressure transmitters, smart 3051 differential pressure transmitters, diaphragm seal models, RS485 digital pressure transmitters and high frequency dynamic pressure sensors. Standard outputs include 4-20 mA, voltage output, HART and RS485 Modbus options, with stainless steel wetted parts and custom process connections available on request.

Pressure Transmitter Parameters

Pressure Types	Gauge, absolute, negative pressure, differential pressure
Measuring Range	From low differential pressure to high pressure ranges up to 100 MPa, depending on model
Output Signals	4-20 mA, 0-5 V, 1-5 V, 0-10 V, RS485 Modbus, HART options
Accuracy	Typical options include 0.1%, 0.2%, 0.25% and 0.5% FS
Process Connection	M20 x 1.5, G1/4, G1/2, NPT and customized thread connections
Wetted Materials	Stainless steel, 316L diaphragm and corrosion-resistant sealing options
Media	Water, oil, gas, air, steam and compatible liquid or gas media
Applications	Pipeline pressure, tank level, flow differential pressure, hydraulic pressure and automation systems

Recommended Pressure Transmitter Series

Xinyi YW-150 - differential pressure transmitter for stable industrial measurement.
Xinyi YW-3051DP - smart differential pressure transmitter for process control.
Xinyi YW-130 / YW-140 - compact pressure transmitters for general pressure monitoring.
RS485 Digital Pressure Transmitter - Modbus communication for remote monitoring systems.
High Temperature Pressure Transmitter - designed for hot media and demanding process conditions.
Siemens, Yokogawa and ABB Options - international brand transmitters available for project matching.

Pressure Transmitter FAQ

What is a pressure transmitter used for?

A pressure transmitter converts the pressure of liquid, gas or steam into a standard electrical signal for PLC, DCS, recorder or control instrument input. It is widely used for pipeline pressure, tank level, flow measurement and process safety monitoring.

How do I choose the right pressure transmitter?

Confirm the pressure range, pressure type, medium, temperature, output signal, accuracy, installation thread, electrical connection and environmental requirements. For corrosive media, high temperature or sanitary applications, diaphragm material and sealing structure are especially important.

What is the difference between gauge, absolute and differential pressure transmitters?

Gauge pressure transmitters measure pressure relative to atmospheric pressure. Absolute pressure transmitters measure pressure relative to vacuum. Differential pressure transmitters measure the pressure difference between two points and are commonly used for flow, filter and level measurement.

Can Xinyi Instrument provide customized pressure transmitters?

Yes. Xinyi Instrument can support customized pressure ranges, process connections, output signals, cable length, display options and model selection for different industrial applications.
