1. Core Measurement Technology & Performance

• Accuracy Class: Up to ±0.2% of the measured value (for DN25-DN2000), ensuring high-precision flow monitoring for critical process control. For smaller diameters (DN15), the accuracy remains excellent at ±0.5% of the measured value.
• Flow Velocity Range: 0.01 m/s to 12 m/s (0.033 ft/s to 39.37 ft/s), covering both low-flow and high-flow scenarios, from gentle fluid transfer to high-volume industrial processes.
• Bi-directional Measurement: Supports both forward and reverse flow detection, making it suitable for complex pipeline systems where fluid direction may vary, such as recycling processes or batch operations.
• Empty Pipe Detection: Integrated empty pipe detection function automatically identifies when the pipe is not fully filled, preventing incorrect readings and ensuring process safety.

2. Rugged Construction & Material Options

• Liner Materials: Optional PTFE (Polytetrafluoroethylene), PFA (Perfluoroalkoxy alkane), or hard rubber liners. PTFE and PFA offer exceptional chemical resistance, making them ideal for corrosive media such as acids, alkalis, and aggressive chemicals. Rubber liners are suitable for abrasive fluids like slurries or wastewater.
• Electrode Materials: Multiple options available to match specific media requirements, including 316L stainless steel (for general-purpose applications), Hastelloy C (for strong acids and corrosive chemicals), and Tantalum (for highly aggressive media such as hydrofluoric acid).
• Process Temperature Range: Operates reliably in media temperatures from -20°C to +180°C (-4°F to 356°F), adapting to both low-temperature and high-temperature industrial processes.
• Protection Class: IP67 or IP68, ensuring dust-tight and water-tight performance, even in outdoor or wet industrial environments. IP68 protection allows for temporary submersion, making it suitable for harsh outdoor installations.
